Recent advancements in reward signal usage for Large Language Models (LLMs) are remarkable. However, significant challenges exist when transitioning reward signal to the multimodal domain, including labor-intensive annotations, over-reliance on one-step rewards, and inadequate evaluation. To address these issues, we propose SVIP, a novel approach to train a step-level multi-dimensional Chain-of-Thought~(CoT) reward model automatically. It generates code for solving visual tasks and transforms the analysis of code blocks into the evaluation of CoT step as training samples. Then, we train SVIP-Reward model using a multi-head attention mechanism called TriAtt-CoT. The advantages of SVIP-Reward are evident throughout the entire process of MLLM. We also introduce a benchmark for CoT reward model training and testing. Experimental results demonstrate that SVIP-Reward improves MLLM performance across training and inference-time scaling, yielding better results on benchmarks while reducing hallucinations and enhancing reasoning ability.
View on arXiv@article{gao2025_2504.06606,
title={ Benchmarking Multimodal CoT Reward Model Stepwise by Visual Program },
author={ Minghe Gao and Xuqi Liu and Zhongqi Yue and Yang Wu and Shuang Chen and Juncheng Li and Siliang Tang and Fei Wu and Tat-Seng Chua and Yueting Zhuang },
journal={arXiv preprint arXiv:2504.06606},
year={ 2025 }
}
