Matrix languages, including MATLAB and Octave, are established standards for applications in science and engineering. They provide interactive programming environments that are easy to use due to their scripting languages with matrix data types. Current implementations of matrix languages do not fully utilise high-performance, special-purpose chip architectures such as the IBM PowerXCell processor (Cell), which is currently used in the fastest computer in the world. We present a new framework that extends Octave to harness the computational power of the Cell. With this framework the programmer is relieved of the burden of introducing explicit notions of parallelism. Instead the programmer uses a new matrix data-type to execute matrix operations in parallel on the synergistic processing elements (SPEs) of the Cell. We employ lazy evaluation semantics for our new matrix data-type to obtain execution traces of matrix operations. Traces are converted to data dependence graphs; operations in the data dependence graph are lowered (split into sub-matrices), scheduled and executed on the SPEs. Thereby we exploit (1) data parallelism, (2) instruction level parallelism, (3) pipeline parallelism and (4) task parallelism of matrix language programs. We conducted extensive experiments to show the validity of our approach. Our Cell-based implementation achieves speedups of up to a factor of 12 over code run on recent Intel Core2 Quad processors.
